Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
ED42B100L
ED42B100L is a Siemens 2 Pole molded case circuit breaker with a 100 Amp current rating and 480 Volt AC voltage rating designed for reliable power distribution protection.This Siemens ED frame circuit breaker features a thermal magnetic trip unit, standard interrupting capacity of 18kA at 480V, and complies with UL 489 and IEC 60947-2 standards. It is rated for operation at 40 degrees Celsius and suitable for low voltage applications requiring robust circuit protection.
- Manufacturer: Siemens
- Part Number: ED42B100L
- Current Rating: 100 Amps
- Voltage Rating: 480 VAC
- Number of Poles: 2 Pole
- Frame/Series: ED Frame
- Interrupt Rating: 18kA at 480V
- Trip Unit: Thermal Magnetic
- Mounting Type: Molded Case
- Standards: UL 489, IEC 60947-2
- Operating Temperature: 40¡C
Specifications
- Part Number: ED42B100L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : ED
- Voltage : 480 AC
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : ED Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643083868
- GTIN : 00783643083868
- Country of Origin : Mexico
- Dimensions : 6.693 x 5.906 x 2.781
- Weight : 2.712
- Certification : Ul Listed, IEC
