Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
ED42B080L
ED42B080L is a Siemens 80 Amp 2-pole molded case circuit breaker designed for reliable circuit protection in electrical systems.This thermal magnetic circuit breaker features a 480 Volt AC rating and is suitable for use in a variety of industrial and commercial applications. It provides a high interrupting capacity and complies with UL 489 and IEC 60947-2 standards, ensuring safety and performance. The breaker supports wire sizes from 10 AWG to 1/0 AWG and is part of the Siemens ED series.
- Amperage: 80 Amps
- Voltage Rating: 480 Volts AC
- Poles: 2
- Interrupting Rating: 18 kAIC at 480V
- Trip Type: Thermal Magnetic
- Series: ED
- Wire Range: 10 AWG to 1/0 AWG
- Standards: UL 489, IEC 60947-2
Specifications
- Part Number: ED42B080L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : ED
- Voltage : 480 AC
- Amperage : 80
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : ED Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643314856
- GTIN : 00783643314856
- Country of Origin : Mexico
- Dimensions : 6.693 x 5.906 x 2.777
- Weight : 2.712
- Certification : Ul Listed, IEC
