ED42B080 - Siemens 2 Pole 80 Amp 480V ED Frame Bolt-On Molded Case Circuit Breaker, 18kAIC, Thermal Magnetic Trip, UL 489 / IEC 60947-2

ED42B080

ED42B080 is a Siemens Sentron series 2-pole molded case circuit breaker rated for 80 amperes at 480 volts with thermal-magnetic trip protection and 18kA interrupting capacity at 480V. This bolt-on breaker is designed for commercial and industrial electrical systems requiring reliable overcurrent and short-circuit protection. The ED frame type features a thermal-magnetic trip unit that combines thermal response for overload protection with magnetic response for short-circuit protection, ensuring precise and dependable performance. It includes load-side lug terminals and supports wire sizes from 10 AWG to 1/0 AWG (copper or aluminum). The breaker is HACR rated and suitable for reverse feed applications. Dimensions are 6.35 inches high by 2 inches wide by 3.92 inches deep, with a weight of approximately 2.5 to 2.63 pounds.

• Amperage: 80A
• Poles: 2
• Voltage Rating: 480V AC
• Interrupting Capacity: 18kA at 480V; 65kA at 240V
• Trip Unit: Thermal-Magnetic
• Mounting: Bolt-On
• Frame Type: ED (Sentron Series)
• Wire Range: 10 AWG to 1/0 AWG (CU/AL)
• Connection: Load-Side Lug Terminals
• HACR Rated: Yes
• Dimensions: 6.35"H x 2"W x 3.92"D
• Weight: 2.5 to 2.63 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED42B080
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : ED
• Voltage : 480 AC
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : Lug In Panelboard
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 125A/ED
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• MCM Size : Min. Wire Size 10 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Any

Product Data

• UPC : 783643209312
• GTIN : 00783643209312
• Country of Origin : Mexico
• Dimensions : 6.693 x 5.906 x 2.776
• Weight : 2.63
• Panel Type : SB Switchboards, Sentron Panelboards
• Standards : IEC Certified, UL Listed
• Certification : IEC Certified, UL Listed
