Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
ED42B020L
ED42B020L is a Siemens 2 Pole molded case circuit breaker with a 20 Amp current rating and 480 Volt voltage rating designed for low voltage applications.This Siemens ED frame circuit breaker features a thermal-magnetic trip unit, standard interrupting capacity of 18kA at 480V, and is rated for 40 degree C ambient temperature. It is suitable for mounting with lug connections (lugs not included) and complies with industry certifications for safety and performance.
- Manufacturer: Siemens
- Part Number: ED42B020L
- Current Rating: 20 Amps
- Voltage Rating: 480 Volts
- Poles: 2
- Frame/Series: ED
- Trip Unit: Thermal-Magnetic
- Interrupt Rating: 18kA at 480V, 65kA at 240V
- Mounting Type: Lug (not included)
- Frequency: 50/60 Hz
- Ambient Temperature Rating: 40¡C
Specifications
- Part Number: ED42B020L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : ED
- Voltage : 480 AC
- Amperage : 20
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : ED Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643083776
- GTIN : 00783643083776
- Country of Origin : Mexico
- Dimensions : 6.693 x 5.906 x 2.759
- Weight : 2.712
- Certification : Ul Listed, IEC
