ED3150S22 - Eaton Cutler Hammer 150A 240V 3-Pole Molded Case Circuit Breaker Series C F-Frame

ED3150S22

ED3150S22 is a 150 amp, 3-pole molded case circuit breaker from Eaton's Cutler Hammer Series C, designed for reliable circuit protection in industrial and commercial applications.This breaker features a 240 Vac and 125 Vdc voltage rating with a fixed thermal and magnetic trip unit (T186), providing a 65kA interrupting rating at 240 Vac. It is a bolt-on mounting type with an F-frame design, ensuring compatibility with standard panelboards and switchboards.

• Amperage: 150 A
• Voltage Rating: 240 Vac, 125 Vdc
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65 kA at 240 Vac
• Series/Frame: Series C, F-Frame
• Trip Unit: Fixed Thermal Magnetic (T186)
• Certifications: UL Listed
• Terminal Connection: Screw
• Wire Size Range: 4-4/0 AWG

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED3150S22
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : ED
• Voltage : 240
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78667902539
• GTIN : 00786679025390
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
