ED2200 - Cutler Hammer 200 Amp 240V 2 Pole Thermal Magnetic Circuit Breaker Series C ED Frame

Save $327.61
SKU: ED2200-New
Condition: New
Price:
$426.27 $753.88
Stock:
37 In stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

ED2200 - Eaton/ Westinghouse/ Cutler Hammer Bolt-On 200 Amp 2 Pole Circuit Breaker - Essential Electric Supply
ED2200 - Eaton/ Westinghouse/ Cutler Hammer Bolt-On 200 Amp 2 Pole Circuit Breaker - Essential Electric Supply
ED2200 - Cutler Hammer 200 Amp 240V 2 Pole Thermal Magnetic Circuit Breaker Series C ED Frame - Essential Electric Supply
ED2200 - Cutler Hammer 200 Amp 240V 2 Pole Thermal Magnetic Circuit Breaker Series C ED Frame - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
ED2200 - Eaton/ Westinghouse/ Cutler Hammer Bolt-On 200 Amp 2 Pole Circuit Breaker - Essential Electric Supply
ED2200 - Eaton/ Westinghouse/ Cutler Hammer Bolt-On 200 Amp 2 Pole Circuit Breaker - Essential Electric Supply
ED2200 - Cutler Hammer 200 Amp 240V 2 Pole Thermal Magnetic Circuit Breaker Series C ED Frame - Essential Electric Supply
ED2200 - Cutler Hammer 200 Amp 240V 2 Pole Thermal Magnetic Circuit Breaker Series C ED Frame - Essential Electric Supply

Description

ED2200


ED2200 is a Cutler Hammer 2 pole, 200 amp, 240 volt thermal magnetic molded case circuit breaker designed for reliable circuit protection.This Series C ED frame breaker features a bolt-on mounting type with long-time and instantaneous trip functions. It has a 65kA interrupting rating at 240VAC and is UL, CSA, and CE certified. The breaker supports line and load side lug connections and is suitable for industrial and commercial electrical systems.
  • Manufacturer: Cutler Hammer (Eaton)
  • Amperage: 200 A
  • Voltage: 240 VAC, 125 VDC
  • Poles: 2
  • Mounting Type: Bolt-On
  • Interrupting Rating: 65kA at 240 VAC
  • Series/Frame: Series C, ED Frame
  • Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Trip
  • Certifications: UL, CSA, CE
  • Connection Type: Line and Load Side Lug
  • Dimensions: 6" H x 2.75" W x 3.38" D
  • Weight: Approximately 3 lbs
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: ED2200
  • Manufacturer : Cutler Hammer
  • Brand : Eaton
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Series C
  • Type : ED
  • Voltage : 240
  • Amperage : 200
  • Phase : 2
  • Poles : 2
  • AIC rating : 65kA@240V
  • Connection : Lug In Panelboard
  • Functions : LI - Long-Time and Instantaneous Trip
  • Terminal Connection : Load Side Lug
  • Frame Size : 225A/F
  • Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
  • MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
  • Breaker Type : Standard
  • Protection : Thermal Magnetic
  • Phase Connection : AB

Product Data

  • UPC : 786679456224
  • GTIN : 00786679456224
  • Country of Origin : Dominican Republic
  • Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
  • Weight : 2.9
  • Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Standards : CSA Certified, IEC Rated, UL Listed
  • Certification : CSA Certified, IEC Rated, UL Listed
