ED2175L - Cutler Hammer 175A 240VAC 2 Pole Molded Case Circuit Breaker ED Series

ED2175L

ED2175L is a Cutler Hammer molded case circuit breaker with a 175 amp rating and 2 poles designed for reliable circuit protection.ED2175L features a 240VAC and 125VDC voltage rating, thermal magnetic trip unit with long-time and instantaneous trip functions, and a 65kA interrupting rating at 240VAC. It is a bolt-on mounted breaker from the ED series (C frame) with line and load side lug terminals and UL certification.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 175A
• Voltage: 240VAC, 125VDC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupting Rating: 65kAIC at 240VAC
• Series/Frame: ED (C Series)
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Terminal Connection: Line and Load Side Lug
• Certifications: UL Listed
• Temperature Rating: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED2175L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : ED
• Voltage : 240
• Amperage : 175
• Phase : 2
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679454121
• GTIN : 00786679454121
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 2.9
• Certification : UL Listed
