ED2175 - Cutler Hammer 175A 2-Pole 240VAC/125VDC Molded Case Circuit Breaker, Series C F-Frame, Fixed Thermal-Magnetic Trip, 65kA Interrupt, Panel Mount

ED2175

ED2175 is a Cutler Hammer Series C molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This 2-pole breaker features a 175A amperage rating, 240VAC/125VDC voltage rating, and a robust F-frame construction. It is equipped with a fixed thermal-magnetic trip unit (T186) for precise overcurrent protection and offers a high 65kA interrupt rating at 240VAC. The ED2175 is panel-mounted and is engineered for durability and safety in demanding environments.

Key Specifications
• Part Number: ED2175
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 175A
• Voltage: 240VAC, 125VDC
• Poles: 2
• Mounting Type: Panel
• Interrupt Rating: 65kA @ 240VAC
• Series/Frame: Series C, F-Frame
• Trip Unit: Fixed Thermal-Magnetic (T186)
• Termination: Busbar (line side), load terminals
• Certifications: Not specified in available data

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED2175
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : ED
• Voltage : 240
• Amperage : 175
• Phase : 2
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679456286
• GTIN : 00786679456286
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 2.9
• Certification : UL Listed
