Product Info
- Manufacturer:Edison Fuses
Description
ECSR9
ECSR9 is a 9 amp, 600 volt Class RK5 dual-element time-delay fuse from Edison Fuses designed for reliable motor overload and short-circuit protection.This fuse features superior overload and cycling capabilities with a 200kA interrupt rating, making it suitable for circuits with surge currents such as motors and transformers. It is UL, CSA, and CE certified, providing current-limiting protection with a minimum 10-second time delay at 500% rated current.
- Amperage: 9 Amps
- Voltage Rating: 600 VAC
- Fuse Class: RK5
- Fuse Type: Dual-Element, Time-Delay
- Interrupt Rating: 200kA RMS Symmetrical
- Certifications: UL 248-12, CSA C22.2 No. 248.12, CE
- Current Limiting
- Superior overload and cycling capabilities
- Non-indicating
- Size: 5 inch length, 0.81 inch diameter
Specifications
- Part Number: ECSR9
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
Product Data
- UPC : 782001717274
- GTIN : 00782634508274
- Dimensions : 7.88 in x 1.11 in x 1.11 in (Length/Depth x Height x Width)
- Weight : 0.38
