Product Info
- Manufacturer:Eaton
- Sub-Category:Dual Element Fuses
Description
ECSR7
ECSR7 is a 7 ampere, 600 volt Class RK5 time-delay dual element power fuse from Edison Fuses designed for reliable circuit protection.This fuse features a 10 second time delay at 500% rated load, ferrule terminal type, and a high interrupting rating of 200 kiloamperes symmetrical. It is UL, CSA C22.2, and CE approved, suitable for branch and feeder circuits, AC drives, load centers, panel boards, and switchboards. The fuse measures 5 inches in length with a diameter of 0.81 inches and weighs approximately 0.14 lbs.
- Key Specifications
- Amperage Rating: 7 Amps
- Voltage Rating: 600 VAC
- Fuse Class: RK5
- Time Delay: 10 seconds at 500% rated load
- Interrupting Rating: 200 kAIC (kiloamperes symmetrical)
- Terminal Type: Ferrule
- Fuse Type: Dual Element, Time-Delay
- Length: 5 Inches
- Diameter: 0.81 Inches
- Certifications: UL, CSA C22.2, CE
- Application: Branch and feeder circuit protection, AC drives, load centers
Specifications
- Part Number: ECSR7
- Manufacturer : Eaton
- Brand : Eaton
- Category : Fuse
- Item Subcategory : Dual Element Fuses
- Section : Fuse
Product Data
- UPC : 782634508250
- GTIN : 00782634508250
- Dimensions : 7.88 in x 1.11 in x 1.11 in (Length/Depth x Height x Width)
- Weight : 0.38
