ECSR250 - Edison Fuses 250A 600VAC Class RK5 Current-Limiting Time-Delay Knife Blade Fuse

ECSR250

ECSR250 is a 250 amp, 600 VAC Class RK5 current-limiting time-delay fuse with a knife blade body type designed for feeder and branch protection.This Edison fuse from the ECSR series features a 200 kA interrupt rating and time-delay curve characteristics, making it suitable for industrial and commercial electrical applications requiring reliable overcurrent protection. It measures 2.34 inches in diameter and 11.63 inches in length, and is UL listed (File #E162363) and CSA certified (File #700489).

• Amperage Rating: 250A
• Voltage Rating: 600 VAC
• Fuse Class: RK5
• Current Limiting: Yes
• Time-Delay Curve
• Body Type: Knife Blade
• Interrupt Rating: 200 kAIC
• Dimensions: 2.34 x 11.63 inches
• Application: Feeder/Branch Protection
• UL Listed File #: E162363
• CSA Certified File #: 700489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ECSR250
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : ECSR Series
• Type : ECSR
• Voltage : 600
• Amperage : 250
• AIC rating : 200kA@600V
• Connection : Rejection Blade
• Diameter : 2.34
• Class Rating : RK5
• Barrels : 1

Product Data

• UPC : 78263450850
• GTIN : 00782634508502
• Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 0.4
