Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
ECSR20
ECSR20 is a 20 Amp, 600 Volt, Class RK5 dual-element time-delay fuse designed for motor overload, ground fault, and short-circuit protection.This Edison fuse features a dual-element, time-delay design providing superior overload and cycling capabilities. It is UL listed and CSA certified, rated for 600 VAC with a 200kA interrupt rating, and suitable for use in circuits with surge currents such as motors and transformers. The fuse has a cartridge body type with ferrule end connections and is 5 inches long with a diameter of 0.81 inches.
- Key Specifications
- Amperage: 20 A
- Voltage Rating: 600 VAC
- Class: RK5
- Fuse Type: Dual-Element, Time-Delay
- Interrupt Rating: 200kA RMS Symmetrical
- Length: 5 inches
- Diameter: 0.81 inches
- Mounting Type: Cartridge
- Certifications: UL Listed, CSA C22.2, CE
- Body Type: Ferrule End X Ferrule End
Specifications
- Part Number: ECSR20
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 600
- Amperage : 20
- AIC rating : 200kA@600V
- Connection : Ferrule
- Diameter : 3
- Class Rating : E
- Barrels : 1
Product Data
- UPC : 78263450832
- GTIN : 00782634508328
- Country of Origin : United States
- Dimensions : 9.63 in x 1.61 in x 1.61 in (Length/Depth x Height x Width)
- Weight : 1.5
