Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
ECNR350
ECNR350 is a Class RK5, time-delay, current-limiting fuse designed for feeder and branch circuit protection in industrial and commercial applications. This Edison Fuses ECNR series fuse features a dual-element, knife blade design for reliable performance under high fault conditions. It provides superior overload and cycling capabilities, making it ideal for motor backup and general circuit protection.
- Amperage Rating: 350A
- Voltage Rating: 250 VAC/VDC
- Fuse Class: Class RK5
- Current-Limiting: Yes
- Curve Characteristics: Time-delay
- Body Type: Knife blade
- Interrupt Rating: 200 kA symmetrical
- Series: ECNR
- Mounting Type: Blade end x blade
- Agency Approvals: UL Listed, CSA Recognized
- Application: Feeder/branch protection
- Weight: 1.6 lbs
Specifications
- Part Number: ECNR350
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 250
- Amperage : 350
- AIC rating : 200kA@250V
- Diameter : 2.38
- Class Rating : RK5
- Barrels : 1
Product Data
- UPC : 782634507529
- GTIN : 00782634507529
- Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
- Weight : 0.5
