Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
ECNR25
ECNR25 is a 25 Amp, 250 Volt Class RK5 dual-element time-delay fuse from Edison designed for motor overload and short-circuit protection.This fuse provides current-limiting protection with a time-delay feature allowing 8 seconds minimum at 500% rated current, suitable for feeder and branch circuit applications. It is UL listed, ferrule-ended, and rated for 250 VAC and 125 VDC with a 200kA interrupt rating. The fuse helps prevent motor burnout from overloads and single-phasing, simplifying blackout prevention and selective coordination.
- Key Specifications
- Amperage: 25 Amps
- Voltage Rating: 250 VAC, 125 VDC
- Fuse Class: RK5
- Fuse Type: Dual-Element, Time-Delay
- Interrupt Rating: 200kA RMS Symmetrical
- Mounting Type: Ferrule Ends
- Dimensions: 0.56 in x 2 in
- Approvals: UL Listed, cULus Listed, CE, CSA Certified
- Country of Origin: Mexico
- Application: Motor overload, ground fault, short-circuit protection
Specifications
- Part Number: ECNR25
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : ECNR Series
- Type : ECNR
- Voltage : 250
- Amperage : 25
- AIC rating : 200kA@250V
- Connection : Ferrule
- Diameter : 0.56
- Class Rating : RK5
- Barrels : 1
Product Data
- UPC : 782634507338
- GTIN : 00782634507338
- Dimensions : 8.63 in x 2.38 in x 2.38 in (Length/Depth x Height x Width)
- Weight : 1.95
