ECNR1.5 - Edison Fuses 1.5A 250V Dual-Element Time-Delay Class RK5 Fuse

ECNR1.5

ECNR1.5 is a 1.5 amp, 250 volt dual-element time-delay fuse from Edison Fuses, designed for reliable circuit protection.This ECNR1.5 fuse is part of the Class RK5 series, featuring a 0.56 inch diameter barrel and a 2 inch length. It provides a 200,000 RMS symmetrical amp interrupt rating and is rated for 250 VAC and 125 VDC. The fuse is UL, CSA C22.2, and CE certified, offering superior protection against motor overloads, short circuits, and ground faults with a time-delay characteristic to withstand temporary surges.

Key Specifications
• Amperage: 1.5A
• Voltage Rating: 250 VAC, 125 VDC
• Fuse Type: Dual-element, time-delay
• Class: RK5
• Interrupt Rating: 200 kA RMS symmetrical
• Dimensions: 0.56 inch diameter, 2 inch length
• Mounting: Barrel fuse style
• Certifications: UL, CSA C22.2, CE
• Application: Motor overload and short circuit protection
• Response Time: 8 seconds at 500% rated current
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: ECNR1.5
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : ECNR Series
• Type : ECNR
• Voltage : 250
• Amperage : 1.5
• AIC rating : 200kA@250V
• Connection : Ferrule
• Diameter : 0.56
• Class Rating : RK5
• Barrels : 1



Product Data

• UPC : 78263450696
• GTIN : 00782634506966
• Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.5
