Product Info
- Manufacturer:Edison Fuses
Description
ECNR0.25
ECNR0.25 is a Class RK5 time delay fuse designed for reliable overcurrent protection in electrical circuits. This Edison Fuses ECNR0.25 is a dual-element, current-limiting, time-delay fuse suitable for applications requiring superior overload and cycling capabilities. It features a cylindrical body with ferrule ends and is non-indicating. The fuse is rated for 250VAC and 125VDC, with a 200kA RMS symmetrical interrupting rating, making it ideal for industrial and commercial power distribution systems.
- Part Number: ECNR0.25
- Manufacturer: Edison Fuses
- Fuse Type: Class RK5
- Amperage Rating: 0.25A
- Voltage Rating: 250VAC / 125VDC
- Interrupting Rating: 200kAIC
- Response Time: Time Delay (8 seconds at 500% load)
- Mounting Type: Ferrule End x Ferrule End
- Series/Frame: ECNR
- Indicating: Non-indicating
- Certifications: UL Listed
- Application: Overcurrent Protection
Specifications
- Part Number: ECNR0.25
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
Product Data
- Weight : 5.19
