ECNR0.15 - Edison Fuses 0.15A 250V Class RK5 Time-Delay Fuse

ECNR0.15

ECNR0.15 is a 0.15 amp, 250 volt, Class RK5 time-delay fuse from Edison Fuses designed for reliable circuit protection.This fuse features a dual-element, current-limiting design with a time-delay response, providing motor overload, ground fault, and short-circuit protection. It has an interrupt rating of 200kA RMS symmetrical and is suitable for industrial and commercial electrical applications. The fuse is rated for 8 to 10 seconds minimum delay at 500% of rated current, helping to prevent nuisance blowing during temporary overloads.

• Amperage: 0.15 A
• Voltage Rating: 250 VAC / 125 VDC
• Fuse Class: RK5
• Time-Delay, Dual-Element
• Interrupt Rating: 200 kA RMS Symmetrical
• Mounting Type: Cartridge Body, Ferrule End x Ferrule End
• Response Time: 8 to 10 seconds at 500% rated current
• Agency Approvals: UL 248-12, cULus Listed, CE, CSA Certified
• Application: Motor overload, ground fault, short-circuit protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ECNR0.15
• Manufacturer : Edison Fuses
• Brand : Edison Fuses

Product Data

• Weight : 5.19
