E50KL573 - Cutler Hammer E50 Series Limit Switch Operator, 10A, 600V, Lever Actuator, NEMA 1/3/4/6, UL CSA CE Certified

E50KL573

E50KL573 is a Cutler Hammer E50 Series limit switch operator designed for reliable motor control applications.This limit switch features a 2.5 inch lever actuator with a 1 inch wide Nylatron roller, suitable for side rotary use. It supports up to 10 amps and 600 volts, and is rated for multiple NEMA environments including NEMA 1, 3, 3S, 4, 4X, 6, 6P, and 13. Constructed with durable materials such as die-cast zinc and stainless steel, it is UL Listed, CSA Certified, and CE Marked for safety and compliance. The switch operates reliably within a temperature range of 10°F to 200°F and offers a torque rating of 1.8 in-oz minimum return.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Series: E50
• Part Number: E50KL573
• Amperage: 10A
• Voltage: 600V
• Actuator Type: Lever with Nylatron roller
• Lever Length: 2.5 inches
• Environmental Rating: NEMA 1, 3, 3S, 4, 4X, 6, 6P, 13
• Material: Die-cast zinc, stainless steel, Nylatron
• Certifications: UL Listed, CSA Certified, CE Marked
• Operating Temperature: 10°F to 200°F (-12°C to 93°C)
• Torque Rating: 1.8 in-oz minimum return
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: E50KL573
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory
• Section : Limit Switch
• Family : E50 Series
• Type : E50KL



Product Data

• UPC : 782113344737
• GTIN : 00782113344737
• Country of Origin : Mexico
• Dimensions : 3.22 in x 1.29 in x 0.75 in (Length/Depth x Height x Width)
• Weight : 0.1 lb
• Certification : CSA Certified,CE,UL Listed,RoHS Compliant
