E50DD1 - Cutler Hammer E50 Series Heavy-Duty Plug-In Limit Switch Head Side Rotary Lever NEMA 1/3/3S/4/4X/6/6P/13 IP67 600V 10A

E50DD1

This limit switch head features a modular design for easy installation and maintenance, constructed with a die-cast zinc enclosure for durability. It supports multiple NEMA ratings including 1, 3, 3S, 4, 4X, 6, 6P, and 13, and offers IP67 protection for resistance against dust and water ingress. Rated for 600 volts and 10 amperes, it operates effectively within a temperature range of 14°F to 201°F (-10°C to 94°C). The switch uses a two-step rotary lever actuator for precise control and is CSA certified, UL listed, and RoHS compliant.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: E50DD1
• Type: Heavy-Duty Plug-In Limit Switch Head
• Actuator: Side Rotary Lever, Two-Step
• Voltage Rating: 600V
• Amperage: 10A
• NEMA Ratings: 1, 3, 3S, 4, 4X, 6, 6P, 13
• IP Rating: IP67
• Enclosure Material: Die Cast Zinc
• Operating Temperature: 14°F to 201°F (-10°C to 94°C)
• Certifications: CSA Certified, UL Listed, RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: E50DD1
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory
• Section : Limit Switch
• Family : E50 Series
• Type : E



Product Data

• UPC : 078211330887
• GTIN : 00782113308876
• Country of Origin : Mexico
• Dimensions : 1.05 in x 2.46 in x 1.54 in (Length/Depth x Height x Width)
• Weight : 0.11 lb
• Certification : CSA Certified,UL Listed,RoHS Compliant
