E50BW16P - Cutler Hammer Heavy Duty Plug-In Limit Switch, 10A, 2NO-2NC, Wobble Stick Actuator

E50BW16P

E50BW16P is a heavy duty plug-in limit switch from Cutler Hammer designed for reliable industrial control applications.This limit switch features a wobble stick actuator with a contact configuration of 2 normally open (NO) and 2 normally closed (NC) contacts. It supports a contact rating of 10 amperes at 120/240/480/600 VAC and 1 ampere at 125/250 VDC. The enclosure is made of die cast zinc, providing durability and protection. It is suitable for NEMA ratings 1, 3, 3S, 4, 4X, 6, 6P, and 13 environments. The mounting style is free hanging with cable termination using SOOW-A cable.

Key Specifications
• Manufacturer: Cutler Hammer
• Part Number: E50BW16P
• Contact Rating: 10A at 600 VAC, 1A at 250 VDC
• Contact Configuration: 2NO-2NC (Double Pole)
• Actuator Type: Wobble Stick
• Enclosure Material: Die Cast Zinc
• Mounting Style: Free Hanging
• Termination Style: Cable (SOOW-A)
• NEMA Ratings: 1, 3, 3S, 4, 4X, 6, 6P, 13
• Operating Temperature Range: 14°F to 250°F
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: E50BW16P
• Brand : Cutler Hammer



Product Data

• UPC : 78211314907
• GTIN : 00782113149073
• Dimensions : 1.54 in x 4.67 in x 3.03 in (Length/Depth x Height x Width)
• Weight : 2.1
