E50AS3 - Eaton Heavy Duty Plug-In Limit Switch 10A 240VAC 1 Pole Side Push Roller NEMA 1/3/3S/4/4X/6/6P/13

E50AS3

E50AS3 is a heavy duty plug-in limit switch from Eaton designed for reliable industrial automation applications.This limit switch features a side push roller actuator with 1 normally open (NO) and 1 normally closed (NC) contact configuration. It supports a maximum continuous AC current of 10A at 240 VAC and 1A at 250 VDC. The switch is constructed with a durable die cast zinc enclosure and offers extensive environmental protection with NEMA ratings 1, 3, 3S, 4, 4X, 6, 6P, and 13, as well as IP67. It uses screw terminal connections and operates within a temperature range of 14°F to 201°F. The product is UL listed and RoHS compliant, ensuring safety and environmental standards.

Key Specifications
• Amperage: 10A continuous at 240 VAC, 1A at 250 VDC
• Voltage Rating: 240 VAC / 250 VDC
• Poles: 1 Pole
• Actuator Type: Side Push Roller
• Contact Configuration: 1 NO - 1 NC
• Mounting Type: Plug-In Assembly
• Enclosure Material: Die Cast Zinc
• Environmental Rating: NEMA 1, 3, 3S, 4, 4X, 6, 6P, 13; IP67
• Operating Temperature: 14°F to 201°F
• Connection Type: Screw Terminals
• Certifications: UL Listed, RoHS Compliant
• Series: E50

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: E50AS3
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Automation
• Item Subcategory : Limit Switches
• Family : E50A
• Type : E50A
• Voltage : 600V
• Amperage : 10A
• Poles : 1
• Nema Rating : NEMA 1/2/3S/4X/6P/13
• Duty : Heavy Duty

Product Data

• UPC : 078211330743
• GTIN : 00782113307435
• Country of Origin : Mexico
• Dimensions : 4.22 in x 2.25 in x 1.54 in (Length/Depth x Height x Width)
• Weight : 1.1
• Certification : CE, CSA, UL
