E50ANR1 - Eaton E50 Heavy Duty Plug-In Limit Switch, 10A 12VAC, 1A 125VDC, 1 Pole, Side Rotary Actuator, NEMA 1/3/4/6/13

E50ANR1

E50ANR1 is an Eaton E50 series heavy duty plug-in limit switch designed for reliable industrial automation control.This limit switch features a side rotary actuator with a standard spring return and neon indicator light. It has a contact configuration of 1 normally open (NO) and 1 normally closed (NC) contact rated for 10A at 12 VAC and 1A at 125 VDC. The enclosure is made of die cast zinc and is rated for multiple NEMA environments including 1, 3, 3S, 4, 4X, 6, 6P, and 13, providing robust protection and IP67 ingress resistance. The switch uses screw terminal connections and operates reliably in temperatures from 10°F to 200°F. It is UL listed, CSA certified, CE marked, and RoHS compliant.

• Part Number: E50ANR1
• Manufacturer: Eaton
• Series: E50
• Contact Rating: 10A at 12 VAC, 1A at 125 VDC
• Contact Configuration: 1 NO - 1 NC
• Actuator Type: Side Rotary, Standard Spring Return
• Enclosure Material: Die Cast Zinc
• Environmental Rating: NEMA 1, 3, 3S, 4, 4X, 6, 6P, 13, IP67
• Connection Type: Screw Terminals
• Operating Temperature: 10°F to 200°F (-10°C to 93°C)
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Indicator: Neon Light

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: E50ANR1
• Manufacturer : Eaton
• Brand : Eaton
• Category : Automation
• Item Subcategory : Automation Switch
• Section : Limit Switch

Product Data

• UPC : 782113308845
• GTIN : 00782113308845
• Dimensions : 4.22 in x 2.25 in x 1.54 in (Length/Depth x Height x Width)
• Weight : 1.1
