Product Info
- Manufacturer:Edison Fuses
Description
E15S70
E15S70 is a special purpose electrical fuse by Edison Fuses designed for reliable circuit protection with a 70 amp rating and 150Vdc/500Vac voltage capability.The E15S70 fuse features a 70 amp rated current, 150 volts DC and 500 volts AC voltage rating, and an interrupting rating of 200kA RMS symmetrical. It is a non-indicating, ultra rapid fuse suitable for special purpose applications requiring high breaking capacity and fast response.
- Rated Current: 70 Amps
- Rated Voltage: 150V DC / 500V AC
- Interrupting Rating: 200kA RMS Symmetrical
- Fuse Type: Special Purpose Ultra Rapid
- Non-indicating style
- Length: Approximately 2.656 inches
- Melting I2t: 467
- Clearing I2t: 4000 at 150V
- Watts Loss at Rated Current: 6.9 W
- Class/Form: Form 101
- Compliance: RoHS Compliant
Specifications
- Part Number: E15S70
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
Product Data
- Weight : 5.19
