E1016-1603S45 - Eaton Wiring Devices Cam-Lok Receptacle 400A

E1016-1603S45

E1016-1603S45 is an Eaton Crouse-Hinds Cam-Lok J Series insulated male receptacle designed for high-amperage industrial applications. This single-pole connector features a double cam principle for vibration-proof connections and is color-coded orange for easy phase identification. The receptacle accepts cable sizes #2 AWG to 4/0 AWG and is rated for continuous operation up to 400 amperes at 600 volts AC/DC. The watertight thermoplastic elastomer (TPE) body is molded with recessed contacts protected by an insulating jacket, and the unit is safety insulated for direct mounting to steel panels. It features a 1-1/8 inch threaded stud connection and operates reliably across a temperature range of -40°C to 105°C. The locked contacts withstand a pulling force of 1000 pounds, and a 1/3 turn assures high-pressure contact approaching 600 pounds per square inch. Key Specifications

• Part Number: E1016-1603S45
• Manufacturer: Eaton
• Voltage Rating: 600 V
• Amperage Rating: 400 A
• Cable Size: #2-4/0 AWG
• Connection Type: 1-1/8 inch Threaded Stud
• Gender: Male
• Material: Thermoplastic Elastomer (TPE)
• Color: Orange
• Temperature Rating: -40°C to 105°C
• NEMA Rating: 3R

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: E1016-1603S45
• Manufacturer : Eaton
• Brand : Eaton
• Category : Wiring Devices
• Item Subcategory : Single pole devices
• Type : Threaded stud
• Voltage : 600 V
• Amperage : 400 A
• Terminal Connection : 1-1/8 inch Threaded Stud
• MCM Size : #2-4/0 AWG
• Nema Rating : 3R
• Operating Temperature Maximum Celsius : -40°C to 105°C
• Circuit Breaker Mounting Style : Panel Mount
• Material : Thermoplastic Elastomer (TPE)
• Color : Orange
• Gender : Male

Product Data

• UPC : 662275985910
• GTIN : 00662276000000
• Dimensions : 5.13 in x 1.5 in x 1.5 in (Length/Depth x Height x Width)
• Weight : 1 lb
