E1015-8336 - Eaton Wiring Devices Cam-Lok Plug 150A

E1015-8336

E1015-8336 is an Eaton Crouse-Hinds Cam-Lok J Series single pole female plug designed for quick disconnect power systems in industrial and outdoor applications. This non-vulcanized connector features a thermoplastic elastomer (TPE) housing with brass contacts and set screw connection for secure cable termination. The double cam principle provides vibration-proof connections with locked contacts capable of withstanding 1000 lb pulling force, while the self-compensating design eliminates arcing and burning of contacts. Key Specifications

• Part Number: E1015-8336
• Manufacturer: Eaton
• Amperage: 150 A
• Voltage: 600 V
• Wire Size: 8-4 AWG
• Connection Type: Set screw
• Contact Material: Brass
• Housing Material: Thermoplastic elastomer (TPE)
• Gender: Female
• Color: White
• NEMA Rating: 3R
• Operating Temperature: -40 to 105 degrees C
• Dimensions: 0.86 in diameter x 4.61 in length

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: E1015-8336
• Manufacturer : Eaton
• Brand : Eaton
• Category : Wiring Devices
• Item Subcategory : Single pole devices
• Type : Non-vulcanized
• Voltage : 600 V
• Amperage : 150 A
• Connection : Set screw
• Diameter : 0.86 in
• Wire : 8-4 AWG
• Nema Rating : 3R
• Operating Temperature Maximum Celsius : -40 to 105 degrees C
• Material : Thermoplastic elastomer (TPE)
• Color : White
• Contact material : Brass
• Gender : Female

Product Data

• UPC : 662275128041
• GTIN : 00662275000000
• Dimensions : 4.61 in x 0.86 in x 0.86 in (Length/Depth x Height x Width)
• Weight : 0.3 lb
