E1015-8335 - Eaton Wiring Devices Cam-Lok Plug 150A

E1015-8335

E1015-8335 is an Eaton Crouse-Hinds series Cam-Lok J Series E1015 non-vulcanized female plug designed for industrial power distribution and quick disconnect applications. This connector features a double cam principle that provides vibration-proof connections with self-compensating wear characteristics and no moving contact surfaces to eliminate arcing or burning. The locked contacts withstand pulling forces up to 1000 lb, and a 1/3 turn rotation achieves high-pressure contact approaching 600 lb/sq-in for minimum resistance. Key Specifications

• Part Number: E1015-8335
• Manufacturer: Eaton
• Amperage Rating: 150 A
• Voltage Rating: 600 V
• Wire Size: 8-4 AWG
• Connection Type: Set screw
• Contact Material: Brass
• Housing Material: Thermoplastic elastomer (TPE)
• Gender: Female
• Color: Green
• NEMA Rating: 3R
• Temperature Rating: -40 to 105 deg C
• Dimensions: 0.86 in diameter x 4.61 in length

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: E1015-8335
• Manufacturer : Eaton
• Brand : Eaton
• Category : Wiring Devices
• Item Subcategory : Single pole devices
• Type : Non-vulcanized
• Voltage : 600 V
• Amperage : 150 A
• Connection : Set screw
• Diameter : 0.86 in
• Wire : 8-4 AWG
• Nema Rating : 3R
• Operating Temperature Maximum Celsius : -40 to 105 deg C
• Shipping Dimensions : 0.86 in diameter x 4.61 in length
• Material : Thermoplastic elastomer (TPE)
• Color : Green
• Contact material : Brass
• Gender : Female

Product Data

• UPC : 662275128034
• GTIN : 00662275000000
• Dimensions : 4.61 in x 0.86 in x 0.86 in (Length/Depth x Height x Width)
• Weight : 0.3 lb
