Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
DK3350VW
DK3350VW is a Cutler Hammer Series C Type DK molded case circuit breaker rated for 350 amps and 240 volts with 3 poles.This complete molded case circuit breaker features a fixed thermal and fixed magnetic trip unit, designed for reliable thermal magnetic protection. It supports both AC (240V) and DC (250V) applications and has a high interrupting rating of 65kA at 240V. The breaker includes line and load side lug terminals and is built on the K-frame platform for durability and compatibility.
- Key Specifications
- Manufacturer: Cutler Hammer (Eaton)
- Series: C Series
- Type: DK
- Amperage: 350A
- Voltage Rating: 240 VAC / 250 VDC
- Poles: 3
- Interrupt Rating: 65kA at 240V
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Mounting: Complete molded case breaker
- Frame: K-frame
- Part Number: DK3350VW
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : DK
- Voltage : 240
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 65kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- UPC : 786679078051
- GTIN : 00786679078051
- Country of Origin : Dominican Republic
- Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 11.5
- Certification : UL Listed
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
