DFJ-45 - Eaton Bussmann Series 45A 600VAC 450VDC High Speed Fuse

DFJ-45

DFJ-45 is a Bussmann series high speed fuse designed for reliable circuit protection in demanding applications. This fuse provides fast-acting, current-limiting performance for both AC and DC systems, making it ideal for use with variable speed drives and electric controllers.Engineered for maximum protection, the DFJ-45 fuse features Class J construction and is rated for 45A, 600VAC or less, and 450VDC or less. It offers an interrupt rating of 200kA RMS symmetrical at 600VAC and 100kA at 450VDC. The fuse is non-indicating and utilizes a clip termination style for secure mounting in compatible holders.

• 45A current rating
• 600VAC maximum voltage
• 450VDC maximum voltage
• 200kA RMS symmetrical interrupt rating at 600VAC
• 100kA interrupt rating at 450VDC
• Class J fuse type
• High speed, current-limiting design
• Non-indicating
• Clip termination
• RoHS compliant
• UL 248-8 listed
• CSA C22.2 No. 248.8 listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: DFJ-45
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : DFJ Series
• Type : DFJ
• Voltage : 600
• Amperage : 45
• AIC rating : 200kA@600V
• Class Rating : J
• Barrels : 1

Product Data

• UPC : 051712653350
• GTIN : 00051712653350
• Country of Origin : Mexico
• Dimensions : 1 in x 2.4 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.17
• Certification : CE, 248-8, Class J, UL, Guide JDDZ, File E4273, CSA, Class 1422-02, File 53787
