DFJ-40 - Eaton Bussmann 40A 600V AC Class J High Speed Fuse Clip-Lock

DFJ-40

DFJ-40 is a high speed, current-limiting fuse from Eaton Bussmann series designed for AC and DC drive protection.This Class J fuse features a 40 ampere rating, voltage rating up to 600 Vac or 450 Vdc, and a high interrupt rating of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc. It uses a clip-lock mounting type with a melamine tube construction and is non-indicating. The fuse is UL Listed, CSA Certified, CE Marked, and RoHS Compliant.

Key Specifications
• Amperage: 40 A
• Voltage: 600 Vac or less, 450 Vdc or less
• Interrupt Rating: 200 kAIC at 600 Vac, 100 kAIC at 450 Vdc
• Class: Class J
• Mounting Type: Clip-lock
• Fuse Indicator: Non Indicating
• Material: Melamine tube
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Dimensions: 2 in length, 1 in width, 1 in height
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: DFJ-40
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : DFJ Series
• Type : DFJ
• Voltage : 600
• Amperage : 40
• AIC rating : 200kA@600V
• Class Rating : J
• Barrels : 1



Product Data

• UPC : 051712653343
• GTIN : 00051712653343
• Country of Origin : Mexico
• Dimensions : 2 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.169
• Certification : CE, 248-8, Class J, UL, Guide JDDZ, File E4273, CSA, Class 1422-02, File 53787
