Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
DFJ-25
DFJ-25 is a high speed, current-limiting fuse from Eaton's Bussmann series designed for maximum protection of AC and DC drives.This Class J fuse is rated for 25 amps, suitable for voltages up to 600 Vac and 450 Vdc, with a high interrupt rating of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc. It features a melamine tube and clip-lock mounting for secure installation and reliable performance in industrial applications.
- Amperage: 25A
- Voltage Rating AC: 600 Vac
- Voltage Rating DC: 450 Vdc
- Interrupting Rating: 200 kAIC at 600 Vac, 100 kAIC at 450 Vdc
- Class: J
- Poles: 1
- Mounting Type: Clip-lock
- Body Style: Cartridge
- Non-indicating fuse
- Melamine tube construction
- High speed, current-limiting fuse
- Series: Bussmann DFJ
Specifications
- Part Number: DFJ-25
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : DFJ Series
- Type : DFJ
- Voltage : 600
- Amperage : 25
- AIC rating : 200kA@600V
- Class Rating : J
- Barrels : 1
Product Data
- UPC : 051712653312
- GTIN : 00051712653312
- Country of Origin : Mexico
- Dimensions : 0.74 in x 2.27 in x 0.74 in (Length/Depth x Height x Width)
- Weight : 0.9
- Certification : CE, 248-8, Class J, UL, Guide JDDZ, File E4273, CSA, Class 1422-02, File 53787
