DFJ-20 - Eaton Bussmann Class J High Speed Fuse 20A 600V 1-Pole 200kA Interrupt Rating

DFJ-20

This 20 amp fuse is rated for 600 volts AC and 450 volts DC with a 200,000 AIC interrupt rating at 600 VAC and 100,000 AIC at 450 VDC. It features a compact size of approximately 13/16" x 2 1/4" and is UL listed to standard 248-8 and CSA certified. The fuse is designed for solid state motor controllers and power semiconductor protection, offering excellent cycling ability and fast response to overcurrent conditions.

Key Specifications
• Amperage: 20 Amps
• Voltage Rating: 600 VAC / 450 VDC
• Poles: 1
• Interrupt Rating: 200,000 AIC at 600 VAC, 100,000 AIC at 450 VDC
• Fuse Type: Class J High Speed
• Dimensions: 13/16" diameter x 2 1/4" length
• Mounting Type: Cartridge fuse holder
• Certifications: UL Listed 248-8, CSA Certified C22.2 No. 248.8
• Series: Bussmann DFJ
• Application: Protection of AC/DC drives and power semiconductors

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: DFJ-20
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : DFJ Series
• Type : DFJ
• Voltage : 600
• Amperage : 20
• AIC rating : 200kA@600V
• Class Rating : J
• Barrels : 1



Product Data

• UPC : 051712653305
• GTIN : 00051712653305
• Country of Origin : Mexico
• Dimensions : 0.74 in x 2.27 in x 0.74 in (Length/Depth x Height x Width)
• Weight : 0.9
• Certification : CE, 248-8, Class J, UL, Guide JDDZ, File E4273, CSA, Class 1422-02, File 53787
