DFJ-150 - Eaton Bussmann Series Class J High Speed Fuse 150A 600Vac 450Vdc 200kAIC

DFJ-150

DFJ-150 is an Eaton Bussmann series Class J high speed fuse designed for protection of power semiconductors and solid state motor controllers.This fuse features a 150 ampere rating with voltage ratings of 600 Vac or less and 450 Vdc or less. It offers a high interrupt rating of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc. The fuse is non-indicating and constructed with a durable melamine tube for reliable performance in demanding electrical applications.

Key Specifications
• Amperage Rating: 150 A
• Voltage Rating: 600 Vac or less, 450 Vdc or less
• Interrupt Rating: 200 kAIC at 600 Vac, 100 kAIC at 450 Vdc
• Class: Class J
• Fuse Type: High Speed, Current Limiting
• Material: Melamine Tube
• Fuse Indicator: Non Indicating
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Physical Dimensions: 6 in length, 1.73 in height, 1.73 in width
• Weight: 0.76 lb
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: DFJ-150
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : DFJ Series
• Type : DFJ
• Voltage : 600
• Amperage : 150
• AIC rating : 200kA@600V
• Class Rating : J
• Barrels : 1



Product Data

• UPC : 051712653442
• GTIN : 00051712653442
• Country of Origin : Mexico
• Dimensions : 6 in x 1.73 in x 1.73 in (Length/Depth x Height x Width)
• Weight : 0.76
• Certification : CE, 248-8, Class J, UL, Guide JDDZ, File E4273, CSA, Class 1422-02, File 53787
