DFJ-15 - Eaton Bussmann 15 Amp 600 Volt Class J High Speed Fuse

DFJ-15

DFJ-15 is a 15 Amp, 600 Volt AC Class J high speed fuse from Eaton Bussmann designed for maximum protection of AC and DC drives.This current-limiting fuse features a 200,000 AIC interrupt rating at 600 VAC and 100,000 AIC at 450 VDC, making it ideal for solid state motor controllers and power semiconductor protection. It is UL listed to Standard 248-8 and CSA certified, with excellent cycling ability and a compact cartridge size of 13/16" x 2 1/4".

Key Specifications
• Amperage: 15 Amps
• Voltage Rating: 600 VAC, 450 VDC
• Interrupt Rating: 200,000 AIC at 600 VAC, 100,000 AIC at 450 VDC
• Fuse Type: Class J High Speed
• Mounting Type: Cartridge
• Physical Size: 13/16" x 2 1/4"
• UL Listed to Standard 248-8
• CSA Certified to C22.2 No. 248.8
• Designed for Solid State Motor Controllers
• Current Limiting and Excellent Cycling Ability

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: DFJ-15
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : DFJ Series
• Type : DFJ
• Voltage : 600
• Amperage : 15
• AIC rating : 200kA@600V
• Class Rating : J
• Barrels : 1

Product Data

• UPC : 051712653282
• GTIN : 00051712653282
• Country of Origin : Mexico
• Dimensions : 0.74 in x 2.27 in x 0.74 in (Length/Depth x Height x Width)
• Weight : 0.9
• Certification : CE, 248-8, Class J, UL, Guide JDDZ, File E4273, CSA, Class 1422-02, File 53787
