DFJ-125 - Eaton Bussmann 125A 600VAC 450VDC Class J High Speed Fuse Blade End x Blade End

DFJ-125

DFJ-125 is a high speed, Class J fuse from Eaton Bussmann series designed for AC and DC drive protection.This 125 amp fuse is rated for 600 VAC or less and 450 VDC or less, with a high interrupting rating of 200 kAIC at 600 VAC and 100 kAIC at 450 VDC. It features a blade end x blade end connection type and a melamine tube body. The fuse is non-indicating and UL listed, CSA certified, CE marked, and RoHS compliant.

• Amperage: 125 A
• Voltage Rating: 600 VAC, 450 VDC
• Interrupt Rating: 200 kAIC at 600 VAC, 100 kAIC at 450 VDC
• Class: J
• Fuse Type: High Speed
• Connection: Blade end x blade end
• Body Material: Melamine tube
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Mounting Type: Blade
• Non-Indicating
• Designed for AC and DC drives

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: DFJ-125
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : DFJ Series
• Type : DFJ
• Voltage : 600
• Amperage : 125
• AIC rating : 200kA@600V
• Class Rating : J
• Barrels : 1

Product Data

• UPC : 051712653435
• GTIN : 00051712653435
• Country of Origin : Mexico
• Dimensions : 6 in x 1.73 in x 1.73 in (Length/Depth x Height x Width)
• Weight : 0.76
• Certification : CE, 248-8, Class J, UL, Guide JDDZ, File E4273, CSA, Class 1422-02, File 53787
