Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
DFJ-110
DFJ-110 is an Eaton Bussmann Series DFJ high speed fuse designed for maximum protection of AC and DC drives.DFJ-110 is a current-limiting, high speed fuse with a 110 ampere rating, suitable for use at voltages up to 600 VAC or 450 VDC. It features a 200 kA interrupting rating at 600 VAC and 100 kA at 450 VDC, providing reliable protection in demanding electrical environments. This Class J fuse is non-indicating and constructed with standard Class J dimensions for compatibility with common fuse blocks and holders. It is UL Listed and meets CSA and RoHS compliance standards.
- Key Specifications
- Amperage: 110 A
- Voltage Rating: 600 VAC / 450 VDC
- Interrupt Rating: 200 kA at 600 VAC, 100 kA at 450 VDC
- Fuse Class: Class J
- Fuse Type: High Speed, Current-Limiting
- Non-Indicating
- Mounting: Standard Class J dimensions for fuse blocks and holders
- Certifications: UL Listed, cULus Listed, CSA C22.2 No. 248.8, RoHS Compliant
Specifications
- Part Number: DFJ-110
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 600
- Amperage : 110
- AIC rating : 200kA@600V
- Class Rating : RK5
- Barrels : 1
Product Data
- UPC : 05171265342
- GTIN : 00051712653428
- Dimensions : 6 in x 1.73 in x 1.73 in (Length/Depth x Height x Width)
- Weight : 0.76
