Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Motor Control Part And Accessory
Description
D15CR04AB
D15CR04AB is a Cutler Hammer Freedom 600V multi-pole relay designed for motor control applications with a 4-pole configuration and 110/120V coil voltage.This relay features a 4 normally closed (4NC) contact configuration with a 60A make and 6A break contact rating, suitable for 50/60 Hz operation. It supports a rated operational current of 10A and is UL Listed and CSA Certified for safety and reliability. The relay is designed for DIN rail mounting and includes finger-safe, self-lifting pressure plate terminals.
- Key Specifications
- Manufacturer: Cutler Hammer
- Series: D15
- Type: Freedom 600V Multi-Pole Relay
- Number of Poles: 4
- Coil Voltage: 110/120 V AC, 50/60 Hz
- Contact Configuration: 4 Normally Closed (4NC)
- Contact Rating: 60A make, 6A break
- Rated Operational Current: 10A
- Mounting Type: 35 mm DIN Rail
- Terminal Type: Finger Safe, Self-Lifting Pressure Plate
- Certifications: UL Listed, CSA Certified
- Part Number: D15CR04AB
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Motor Control Part And Accessory
- Section : Relays
- UPC : 782113807348
- GTIN : 00782113807348
- Country of Origin : Dominican Republic
- Dimensions : 3.3 in x 2.96 in x 1.8 in (Length/Depth x Height x Width)
- Weight : 0.85
- Certification : UL Listed,CSA Certified
