Product Info
- Manufacturer:WEG
- Sub-Category:Contactor
Description
CWM150N-22-30E10
CWM150N-22-30E10 is a WEG 3-pole contactor designed for motor control applications with a 150 amp rated current and 110-130V AC/DC coil voltage.
This contactor belongs to the WEG CWM series and features a NEMA Size 4 frame. It includes 3 normally open main contacts and auxiliary contacts configured as 2 normally open and 2 normally closed. The device uses screw-type terminals and is suitable for control voltages of 110-130V at 50/60 Hz or DC. It meets insulation voltage standards of 1000 V (IEC) and 600 V (UL, CSA) for pollution degree 3 environments.
- Rated Current: 150 A
- Number of Poles: 3 Pole
- Coil Voltage: 110-130V AC/DC
- Frame Size: NEMA Size 4
- Main Contacts: 3 Normally Open (NO)
- Auxiliary Contacts: 2 NO / 2 NC
- Terminal Type: Screw
- Rated Insulation Voltage: 1000 V (IEC), 600 V (UL, CSA)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: CWM150N-22-30E10
- Manufacturer : WEG
- Brand : WEG
- Category : Motor Control
- Item Subcategory : Contactor
- Family : CWM Series
- Type : CWM
- Voltage : 600
- Amperage : 150
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 130
- Coil Voltage Minimum : 130
Product Data
- Weight : 3
