Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
CVS2060XMM
CVS2060XMM is a Cutler Hammer 2-pole molded case circuit breaker rated for 60 amps and 240 volts with a 42kA interrupting rating.
This circuit breaker is part of the Eaton Type CV series, designed for reliable protection in electrical distribution systems. It supports a maximum conductor size of #4/0 kcmil and includes a mounting kit for easy installation. The breaker is suitable for use with aluminum or copper conductors ranging from #6 to 4/0 AWG.
- Amperage: 60 Amps
- Voltage: 240 Volts AC
- Poles: 2
- Interrupt Rating: 42kAIC
- Series/Frame: Eaton Type CV
- Mounting: Includes mounting kit
- Conductor Size: #6 - 4/0 Al/Cu
- Maximum Load: #4/0 kcmil
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: CVS2060XMM
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CVS Series
- Type : CVS
- Voltage : 240
- Amperage : 60
- Phase : 1
- Poles : 2
- AIC rating : 25kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786685705842
- GTIN : 00786685705842
- Country of Origin : Dominican Republic
- Dimensions : 7.5 in x 5 in x 3.5 in (Length/Depth x Height x Width)
- Weight : 2.75
- Certification : UL 489,CSA Std. C22.2 No. 5
- Wire Size : 6 - 4/0 AWG Cu/Al
