Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
CVH3225X3
CVH3225X3 is a 3 pole, 225 amp, 240V molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems.This Cutler Hammer circuit breaker features a bolt-on mounting design and a thermal magnetic trip unit for precise overcurrent protection. It is part of the CVH series and is rated for a maximum interrupting capacity of 100kA at 240V.
- Part Number: CVH3225X3
- Manufacturer: Cutler Hammer
- Amperage: 225A
- Voltage: 240VAC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 100kAIC @ 240V
- Series/Frame: CVH
- Frame Size: 225A
- Trip Unit: Thermal Magnetic
- Wire Size: #6 - 4/0 AWG Al/Cu
- Maximum Load: #300 kcmil
Specifications
- Part Number: CVH3225X3
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CVH Series
- Type : CVH
- Voltage : 240
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 100kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786685705170
- GTIN : 00786685705170
- Country of Origin : Dominican Republic
- Dimensions : 7.5 in x 5 in x 5 in (Length/Depth x Height x Width)
- Weight : 4.4
- Certification : UL 489,CSA Std. C22.2 No. 5
- Wire Size : #6 to 4/0 AWG CU/AL
