CVH3175X - Cutler Hammer 175A 240V 3-Pole Molded Case Circuit Breaker Type CVH 100kAIC

CVH3175X

CVH3175X is a Cutler Hammer Type CVH molded case circuit breaker rated for 175 amps and 240 volts AC with a 3-pole configuration.This circuit breaker features a thermal magnetic trip unit, a 100 kA interrupt rating, and is designed for use with #6 to 4/0 AWG aluminum or copper conductors. It has a CVH frame type and supports a maximum load of #4/0 kcmil. The breaker is UL 489 and CSA certified, suitable for tenant main breaker applications.

• Amperage: 175 A
• Voltage: 240 VAC
• Poles: 3
• Interrupt Rating: 100 kAIC
• Frame Type: CVH
• Trip Unit: Thermal Magnetic
• Wire Size: #6 - 4/0 AWG Al/Cu
• Maximum Load: #4/0 kcmil
• Mounting Type: Molded Case
• Certifications: UL 489, CSA C22.2 No. 5
• Dimensions: 7.5" L x 5" H x 5" W
• Weight: 4.4 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CVH3175X
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CVH Series
• Type : CVH
• Voltage : 240
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685705132
• GTIN : 00786685705132
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.4
• Certification : UL 489,CSA Std. C22.2 No. 5
• Wire Size : #6 to 4/0 AWG CU/AL
