CVH3150 - Cutler Hammer 150A 240V 3-Pole Molded Case Circuit Breaker, 100kA Interrupt, Type CV Frame

CVH3150

CVH3150 is a Cutler Hammer Type CV molded case circuit breaker rated for 150 amps and 240 volts AC with a 3-pole configuration.This circuit breaker features a 100 kA interrupting rating and thermal/magnetic trip unit, designed for bolt-on mounting with #6 to 4/0 Al/Cu wire terminals. It is certified to CSA Std. C22.2 No. 5 and is part of the CV series frame.

Key Specifications
• Amperage Rating: 150 A
• Voltage Rating: 240 VAC
• Number of Poles: 3
• Interrupt Rating: 100 kAIC
• Trip Unit: Thermal/Magnetic
• Mounting Type: Bolt-On
• Wire Size Range: #6 to 4/0 Al/Cu
• Frame Type: CV
• Certifications: CSA Std. C22.2 No. 5
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CVH3150
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Type : CCV
• Voltage : 240VAC
• Amperage : 150
• Poles : 3
• AIC rating : 100kAIC



Product Data

• UPC : 078668570524
• Dimensions : 7.5 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.4
• Certification : UL, CSA
• Wire Size : AWG 6 to AWG 4/0, Cu/Al
