CVH2150XMM - Cutler Hammer 150A 240V 2-Pole Molded Case Circuit Breaker CVH Series 100kAIC Bolt-On

CVH2150XMM

CVH2150XMM is a Cutler Hammer molded case circuit breaker rated for 150 amps and 240 volts with a 2-pole configuration and 100 kA interrupt rating.This CVH series breaker features bolt-on mounting, thermal/magnetic trip unit, and is suitable for group metering and tenant main breaker applications. It supports wire sizes from #6 to 4/0 AWG aluminum or copper and includes a mounting kit. Certified to CSA Std. C22.2 No. 5 and UL 489 standards.

• Amperage: 150 A
• Voltage: 240 V
• Poles: 2
• Interrupt Rating: 100 kAIC
• Frame/Series: CVH
• Mounting Type: Bolt-On
• Trip Unit: Thermal/Magnetic
• Wire Size Range: #6 - 4/0 AWG Cu/Al
• Certifications: CSA Std. C22.2 No. 5, UL 489
• Includes mounting kit
• Dimensions: 7.5 in L x 4 in H x 3.5 in W
• Weight: 2.75 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CVH2150XMM
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CVH Series
• Type : CVH
• Voltage : 240
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 78668570702
• GTIN : 00786685707020
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 4 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.75
• Certification : CSA Std. C22.2 No. 5,UL 489
• Wire Size : #6 to 4/0 AWG CU/AL
