CVH2060XMM - Cutler Hammer 60A 240V 2-Pole Molded Case Circuit Breaker, Type CV Frame, Thermal Magnetic Trip, 100 kAIC, Bolt-On Mounting

CVH2060XMM

CVH2060XMM is a Cutler Hammer 2-pole molded case circuit breaker designed for reliable protection in commercial and industrial power distribution applications.

This thermal magnetic trip circuit breaker features a 60A current rating, 240V voltage rating, and a high 100 kAIC interrupt rating. It is part of the Type CV series, offers bolt-on mounting, and is suitable for use with #6 to 4/0 Al/Cu conductors. The unit includes a mounting kit for easy installation and is built for demanding environments where safety and performance are critical.

Key Specifications
• Part Number: CVH2060XMM
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 60A
• Voltage: 240V (120/240V AC)
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 100 kAIC
• Series/Frame: Type CV
• Trip Unit: Thermal Magnetic
• Certifications: Not specified in available data
• Maximum Load: #4/0 kcmil
• Dimensions: 7.5" L x 5" H x 3.5" W
• Weight: 2.75 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CVH2060XMM
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CVH Series
• Type : CVH
• Voltage : 240
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685706962
• GTIN : 00786685706962
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.75
• Certification : CSA Std. C22.2 No. 5,UL 489
• Wire Size : 6 AWG to 4/0 AWG, Cu/Al
