CV2225XMM - Cutler Hammer 225 Amp 2 Pole 240V Molded Case Circuit Breaker, 65kAIC, Type CV Frame, Bolt-On Mounting, UL 489, CSA C22.2 No. 5

CV2225XMM

CV2225XMM is a Cutler Hammer molded case circuit breaker designed for reliable protection in commercial and industrial power distribution applications.

This two-pole, 225 amp breaker features a 240V maximum voltage rating, 65kAIC interrupt rating, and a Type CV frame. It is suitable for bolt-on mounting and supports both copper and aluminum conductors. The breaker is certified to UL 489 and CSA C22.2 No. 5 standards, ensuring compliance with North American safety requirements.

Key Specifications

• Part Number: CV2225XMM
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 225 A
• Voltage: 120/240 V
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 65 kAIC
• Series/Frame: Type CV
• Trip Unit: Thermal-Magnetic
• Wire Size: #6–4/0 AWG Cu/Al
• Terminals: #4/0 kcmil maximum load
• Certifications: UL 489, CSA C22.2 No. 5
• Includes mounting kit

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CV2225XMM
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CV Series
• Type : CV
• Voltage : 240
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78668570649
• GTIN : 00786685706498
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.75
• Certification : CSA Std. C22.2 No. 5,UL 489
