CMDL3800F - Westinghouse 800A 600V 3 Pole Molded Case Circuit Breaker 50kA@480V M Frame

CMDL3800F

CMDL3800F is a Westinghouse 3 pole molded case circuit breaker rated for 800 amps and 600 volts with a 50kA interrupting rating at 480 volts.

This breaker features an M frame design and is compatible with electronic RMS 310 trip units. It supports panel mount installation and is UL, CSA, and CE certified for industrial applications. The CMDL3800F is 100% rated and designed for reliable protection in demanding electrical distribution systems.

• Manufacturer: Westinghouse
• Amperage: 800 Amps
• Voltage Rating: 600 VAC at 50/60 Hz
• Poles: 3
• Interrupting Rating: 50kA @ 480V, 65kA @ 240V, 25kA @ 600V
• Frame/Series: M Frame, Series C
• Trip Unit: Electronic RMS 310 (interchangeable)
• Mounting Type: Panel mount (bolt-on)
• Certifications: UL, CSA, CE
• Dimensions: Approx. 8.25" W x 4.06" D x 16" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item is Frame only as definded by the part number. That means it is only the circuit breaker frame, and no lugs or trip unit is included with the frame.

Specifications

• Part Number: CMDL3800F
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CMDL
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : M Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782114366998
• GTIN : 00782114366998
• Country of Origin : Puerto Rico
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL Listed
