Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
CKD3400W
CKD3400W is an Eaton Series C complete molded case circuit breaker designed for panelboard, switchboard, motor control center, and busway applications. This K-frame breaker features fixed thermal and fixed magnetic trip protection with long-time and instantaneous trip characteristics, providing reliable overcurrent protection for industrial and commercial power distribution systems. The unit operates at 50/60 Hz and is rated for both AC and DC service.
- Amperage Rating: 400 A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: 3
- Frame Type: K-frame, Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 25 kAIC at 600 Vac
- Frequency Rating: 50-60 Hz
- Connection Type: Bolt-on
- Certifications: UL Listed
- Circuit Breaker Type: Complete breaker without terminals
Specifications
- Part Number: CKD3400W
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : CKD
- Voltage : 600
- Amperage : 400
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : K Frame
- Protection : Thermal Magnetic
Product Data
- Dimensions : 6" X 6.3" X 7"
- Weight : 12 lb
