CHMDL3800F - Westinghouse 800A 600V 3P M-Frame Molded Case Circuit Breaker, 65kAIC @ 480V, Electronic Trip, 100% Rated, UL/CSA/CE

CHMDL3800F

CHMDL3800F is a Westinghouse Series C M-Frame molded case circuit breaker designed for high-capacity industrial applications.

This three-pole, 800A, 600V AC breaker features an electronic trip unit, 100% rated frame, and a high interrupting capacity of 65kAIC at 480V. It is panel mount, bolt-on style, and is compatible with Challenger systems. The CHMDL3800F is UL, CSA, and CE certified for safety and reliability in demanding environments.

Key Specifications
• Amperage: 800A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: Panel mount, bolt-on
• Interrupt Rating: 65kAIC @ 480V, 35kAIC @ 600V (UL/CSA), 25kAIC @ 600V (IEC)
• Series/Frame: Series C, M-Frame (MDL-frame)
• Trip Unit: Electronic (Digitrip RMS 310, interchangeable)
• Certifications: UL Listed, CSA, CE
• Rating: 100% rated
• Terminal: Aluminum/copper, standard pressure
• Application: Industrial, high interrupting capacity
• Warranty: 1 year from installation or 18 months from shipment

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item is Frame only as definded by the part number. That means it is only the circuit breaker frame, and no lugs or trip unit is included with the frame.

Specifications

• Part Number: CHMDL3800F
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CHMDL
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : M Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782114367001
• GTIN : 00782114367001
• Country of Origin : United States
• Dimensions : 1.1 in x 1.1 in x 1.1 in (Length/Depth x Height x Width)
• Weight : 1.1
• Certification : UL Listed
