Description
CHH2100H4X
CHH2100H4X is a Cutler Hammer 2-pole, 100 amp, 240 volt bolt-on circuit breaker designed for reliable thermal magnetic protection.CHH2100H4X features a CHH frame with a 42kA interrupt rating at 240V, suitable for tenant and main circuit breaker applications. It includes long time and instantaneous trip functions and is engineered for single-phase feed-thru installations.
- Amperage: 100 A
- Voltage: 120/240 VAC
- Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 42 kAIC @ 240V
- Frame/Series: CHH
- Trip Unit: Thermal Magnetic
- Phase: Single
- Feed-Thru Capability
- Certifications: Eaton / Cutler Hammer standard
Specifications
- Part Number: CHH2100H4X
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CHH Series
- Type : CHH
- Voltage : 240
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 42kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 782113032139
- GTIN : 00782113032139
- Dimensions : 9 in x 5.5 in x 4.5 in (Length/Depth x Height x Width)
- Weight : 4.6
- Certification : UL, CSA
