Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
CHF250ST
CHF250ST is a 2-pole thermal magnetic circuit breaker from Eaton designed for 50 amps and 120/240 volts AC applications.This Eaton CH frame plug-on circuit breaker features a 10kA interrupt rating, trip flag, and common trip functionality. It supports #14-2 AWG copper/aluminum wiring and is suitable for residential and commercial power distribution panels.
- Key Specifications
- Amperage: 50 Amps
- Voltage: 120/240 VAC
- Poles: 2
- Frame Type: CH
- Interrupt Rating: 10kAIC
- Mounting Type: Plug-on
- Trip Unit: Thermal Magnetic
- Trip Flag and Common Trip Feature
- Wire Range: #14-2 AWG Cu/Al
- Certifications: UL Listed
- Part Number: CHF250ST
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CH Series
- Type : CH
- Voltage : 240
- Amperage : 50
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Plug-In
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
- UPC : 786685708423
- GTIN : 00786685708423
- Country of Origin : Dominican Republic
- Dimensions : 3.563 in x 6 in x 3.5 in (Length/Depth x Height x Width)
- Weight : 0.75
- Certification : UL Listed,UL 489,HACR Rated
- Wire Size : 14 to 2 AWG, CU/AL
Specifications
