CH2110 - Cutler Hammer 110A 120/240V 2-Pole Thermal Magnetic Circuit Breaker CH Series

CH2110

CH2110 is a Cutler Hammer 110 amp, 120/240 volt, 2-pole thermal magnetic circuit breaker from the CH series designed for reliable circuit protection.This circuit breaker features a common trip thermal magnetic trip unit, suitable for use in Type CH loadcenters. It has a 10 kA interrupt rating at 240 volts, supports #10-1/0 AWG copper/aluminum wiring, and mounts via a plug-in connection. Certified to UL 489 standards, it provides dependable overload and short circuit protection in residential and commercial electrical systems.

• Amperage: 110 A
• Voltage: 120/240 V AC
• Poles: 2
• Interrupt Rating: 10 kAIC at 240 V
• Trip Unit: Thermal Magnetic, Common Trip
• Mounting Type: Plug-In
• Series/Frame: CH Series
• Wire Size: #10-1/0 AWG Cu/Al
• Phase: Single Phase
• Certifications: UL 489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CH2110
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CH Series
• Type : CH
• Voltage : 240
• Amperage : 110
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782113317038
• GTIN : 00782113317038
• Country of Origin : Dominican Republic
• Dimensions : 3.25 in x 3.25 in x 1.5 in (Length/Depth x Height x Width)
• Weight : 0.57 lb
• Certification : UL 489
• Wire Size : AWG 10 to AWG 1/0, AWG 14 to AWG 2, Cu/Al
